Gridfinity Baseplate in FreeCAD: Part 3 - Pads in 2 Dimensions with Pockets and Hole Patterns

A quick tutorial on how to modify Pads to use the TwoDimensions end-condition and add a Pocket with Holes in FreeCAD using #Gridfinity as an example. The pad, pocket, and holes will be used in future videos to create more complex shapes and geometry. Like and Subscribe for more tutorials!

The drawing referenced in the split-screen can be found on the Gridfinity wiki (https://gridfinity.wiki) at this link: https://gridfinity.wiki/assets/images...

The example used is based on Zach Freedman's Gridfinty design, first mentioned in this video: https://youtu.be/ra_9zU-mnl8?si=c6RE5D6GvSx10eZQ

The #Gridfinity generator mentioned in the video can be found here: https://gridfinitygenerator.com/en

#freecad #gridfinity #3dprinting
